MBH
MBH-PET
MBH manufactures high-quality PET sheets extruded from premium virgin PET (Polyethylene Terephthalate) resin. As a leading PET sheet supplier, we offer engineering-grade PET sheets with excellent chemical resistance, low moisture absorption, and superior dimensional stability — ideal for precision-machined parts in humid or wet environments.
Key Features: Chemical Resistant | Low Moisture Absorption | High Dimensional Stability | Good Wear Resistance | High Mechanical Strength | Excellent
Diameters | 3mm to 260mm |
|---|---|
Length | 1000mm / 2000mm |
Colors | Natural |
Tolerance | 0.1mm~0.5mm |
Surface | Smooth,bubble-free |
Cutting | Custom cut-to-length available |
Thickness | 10mm to 100mm |
|---|---|
Length | 1000 x 2000mm |
Tolerance | 0.2mm~1mm |
Cutting | Custom cut-to-length available |
✅ Most standard sizes within this range are regularly stocked and can ship within 24-48 hours after payment.
✅ For custom or non-standard sizes, typical lead time is 3-4 weeks.
✅ For real-time stock availability on your specific size, please contact us or request a quote — we'll confirm stock status and lead time immediately.
Beyond supplying PET sheet and rod, MBH also works directly with clients on custom-machined parts based on their drawings. Over the years, we've found a few design details that are easy to overlook but make a real difference in part quality and turnaround time:
Tolerances. While PET offers excellent dimensional stability, tolerances copied directly from metal part drawings (e.g., ±0.02mm) are often unrealistic for standard machining conditions. We typically recommend working within ±0.1mm–0.2mm unless special process controls are specified — this keeps quality high without unnecessary cost or lead time.
Wall thickness. Parts with uneven wall thickness — thin sections next to thick, stepped areas — can develop mild internal stress during machining due to uneven heat release. We usually flag this during drawing review and can suggest either a more balanced design or a post-machining stress-relief (annealing) step to prevent warping over time.
Threaded holes near edges. PET is strong but has limited flexibility compared to some other engineering plastics, so threaded holes placed too close to a part's edge — or undersized for the thread — can chip or micro-crack during assembly. We recommend adequate edge clearance, and for parts requiring frequent disassembly, metal inserts are often a more durable option than direct tapping.
Surface finish requirements. If a part needs a specific surface finish (e.g., for visual inspection windows or cosmetic surfaces), it's worth specifying this upfront — feed rate and tooling selection directly affect the final surface texture, and unclear specs can lead to avoidable rework.
For technical data, please download the full TDS:
Download Technical Data Sheet (PDF)
✓ RoHS Compliant — Free from restricted hazardous substances (lead, mercury, cadmium, etc.)
✓ REACH Compliant — Meets EU chemical safety regulations
✓ FDA Compliant — Food-grade PET available on request (standard industrial-grade material is not certified for direct food contact unless specified)
✓ COA (Certificate of Analysis) — Batch-specific quality test reports available for every shipment
Certificates and test reports available upon request.
Category | Typical Applications |
|---|---|
Electrical & Electronics | Insulating Parts, Terminal Blocks, Coil Bobbins |
Food & Packaging Machinery | Guide Rails, Wear Strips, Conveyor Components |
Industrial Machinery | Bushings, Gears, Wear Pads, Structural Parts |
Precision Machining | CNC Machined Parts, Jigs & Fixtures, Custom Components |
Whether you need a custom-cut piece, a mold-opened part, or fast-shipping standard stock — our team is ready to help.
Have a drawing or custom specification? Send it to us for a free technical evaluation and quote.
Need standard sizes fast? Check real-time stock availability and get same-week shipping.
