Every few weeks, we get a version of the same question from engineers sourcing parts for hydrogen equipment: "Can you machine this valve seat / seal ring / insulator in [some metal], and if not, what do you recommend instead?"
More often than not, our answer starts with: "You probably don't want metal for this — here's why, and here's which plastic actually fits your application."
This article walks through that conversation — the questions we get asked most, and how we actually answer them when quoting hydrogen components.
Sometimes, yes. But when the part sits in a high-pressure, cyclic-loading hydrogen environment — refueling nozzles, valve seats, compressor components — we'll usually flag a concern first: hydrogen embrittlement.
Under repeated pressure cycling, hydrogen atoms can diffuse into certain steels and alloys and quietly reduce their fracture toughness — sometimes leading to cracking well below the material's rated strength. It's a known risk in exactly the kind of service hydrogen equipment sees: repeated fill/discharge cycles, high pressure, sustained exposure.
Engineering plastics don't have this failure mode — there's no metallic crystal structure for hydrogen to embrittle. That's why we'll often suggest PEEK, or PPS as an alternative before a customer commits to a metal spec that may need re-engineering down the line.
This is the question we get the most, and the honest answer is: it depends on what's actually stressing the part. Fluoropolymers like PTFE are common in the industry for static, low-load sealing, but PTFE tends to creep under sustained compressive load — which is often a problem for bolted parts that need to hold consistent sealing force over years of service, not just pass an initial pressure test.
We machine primarily in PEEK, PPS, PA66+GF, and UHMWPE, and here's how we typically walk customers through choosing between them:
If your part needs... | We usually recommend | Why |
|---|---|---|
High mechanical load + low permeation | PEEK | Strength and stiffness |
Dynamic sealing under continuous movement | PEEK | Better wear and creep resistance than PTFE under load |
High-temp insulation, fuel cell end plates | PPS + GF | Rigid, dimensionally stable above 200°C |
Structural brackets, gears | PA66 + GF | Cost-effective strength where permeation isn't the main concern |
Self-lubricating, low-friction wear parts | UHMWPE | Low friction, good wear resistance, low permeation |
This is where a lot of customers are surprised to learn that material choice alone isn't the whole story — tolerances and finish matter just as much. In hydrogen sealing applications, parts specified in the right material can still underperform because of:
Wall thickness that's too thin for the permeation resistance the material is rated for
Surface finish on sealing faces that's too rough, creating micro-leak paths
Tolerances that don't account for thermal expansion differences between the plastic component and its metal housing
We don't run pressure or permeation testing in-house — for pressure-critical applications, we always recommend qualifying the final assembly through your own test lab or a certified third party before deployment. What we can do is flag geometry and tolerance issues at the drawing stage, before a part goes into testing, so you're not troubleshooting a failed test after the fact.
We get this question because most customers researching hydrogen materials assume they need a different supplier for every part of the system. In practice, the same core materials cover most of it:
Fuel cell stacks — PPS or PEEK for end plates and insulating components
Storage systems (Type IV tanks) — plastic liners, valve components
Electrolyzers (PEM/alkaline) — PEEK or PTFE for insulating and sealing parts exposed to both hydrogen and aggressive electrolytes
Compressors and circulation pumps — UHMWPE or PEEK composite piston rings and guide components
If you're specifying components across more than one of these, it's worth sending the full parts list at once — we can usually standardize on fewer material grades than a part-by-part spec would suggest, which simplifies both sourcing and cost.
We've been machining engineering plastics for 15+ years, serving industries with some of the strictest material and traceability requirements — including medical devices (ISO 13485) and automotive (IATF 16949), alongside ISO 9001 quality management, ISO 14001 environmental management, and ISO 45001 occupational health and safety across all production. Materials are fully traceable, and data sheets and certifications are available on request.
If you're comparing suppliers for a hydrogen application — or going through a supplier qualification process that requires environmental or safety compliance documentation — feel free to ask for our certifications alongside your quote. Happy to provide them upfront.
If you're working through material selection for a hydrogen application — or just want a second opinion on a spec someone else wrote — send us the drawing and duty cycle details. We machine these components in-house from PEEK, PTFE, PPS, PA66+GF, and other hydrogen-compatible materials, and we'll tell you straight if something looks over- or under-specified before you commit to a quote.
