PPSU P3010

Material: Polyphenylsulfone (PPSU) Grade P3010
Brand: MBH / Marbach HT®/Marbach MED®
Form: Sheets / Plates
Color: Amber / Translucent
Reinforcement: Virgin / Unfilled
Sales Model: Wholesale & Direct from Factory
Sample: Available (Shipping Cost to be Paid by Buyer)
MOQ: 10 Pieces

Quantity:
Availability:





Inquire Now ⚡ In Stock: 24-48hr \| Custom: 3-4 Weeks

Model:
P-3010
Brand:
MBH
Code:
MBH-PPSU P-1030

ppsu ppsu material ppsu plastic

Product Description

MBH PPSU P3010 sheets are extruded by us using premium virgin resin from SABIC. These high-performance thermoplastic sheets combine exceptional heat resistance with superior impact strength and inherent steam sterilizability.

Available Rods size

Diameters	3mm to 260mm
Length	1000mm / 2000mm
Colors	Natural
Tolerance	0.1mm~0.5mm
Surface	Smooth, bubble-free
Cutting	Custom cut-to-length available

Available Sheets size

Thickness	10mm to 100mm
Length	630 x 1000mm
Tolerance	0.2mm~1mm
Cutting	Custom cut-to-length available

✅ Most standard sizes within this range are regularly stocked and can ship within 24-48 hours after payment.

✅ For custom or non-standard sizes, typical lead time is 3-4 weeks.

✅ For real-time stock availability on your specific size, please contact us or request a quote — we'll confirm stock status and lead time immediately.

Technical Properties

Property	Typical Value	Unit	Test Standard
Density	1.29	g/cm³	ISO 1183
Tensile Strength	74	MPa	ISO 527
Max. Continuous Service Temperature	180	°C	ISO / ASTM
Elongation at Break	100	%	ISO 527

For complete technical data, please download the full TDS:

Download Full Technical Data Sheet (PDF)

Certifications & Compliance

✓ RoHS Compliant — Free from restricted hazardous substances (lead, mercury, cadmium, etc.)

✓ REACH Compliant — Meets EU chemical safety regulations

✓ FDA Compliant — Suitable for food-contact applications

✓ USP Class VI — Certified biocompatible for medical device use

✓ UL94 V-0 — Inherently flame retardant, verified by independent testing

✓ COA (Certificate of Analysis) — Batch-specific quality test reports available for every shipment

Certificates and test reports available upon request.

Where is it used?

Category	Typical Applications
Medical & Food	Reusable Surgical Instruments, Dental Trays, Sterilization Containers
Aerospace	Aircraft Interior Panels, Air Duct Components, Insulating Parts
Automotive	Sensor Housings, Water Pump Impellers, High-Temperature Gears
General Engineering	Hot Water Valves, Wear Pads,Semiconductor Carriers

Ready to Start Your Project?

Whether you need a custom-cut piece, a mold-opened part, or fast-shipping standard stock — our team is ready to help.

Have a drawing or custom specification? Send it to us for a free technical evaluation and quote.
Need standard sizes fast? Check real-time stock availability and get same-week shipping.
What's App / E-mail

FAQ

Can PPSU withstand repeated steam sterilization (autoclaving)?

Yes, PPSU offers excellent hydrolysis resistance and can withstand thousands of steam autoclave cycles (134°C) without significant loss of mechanical properties — a key reason it's widely used in reusable medical device components.
Should I choose PSU or PPSU for my application?

Choose PSU if cost efficiency and good heat resistance (up to ~174°C) are the priority. Choose PPSU if your application involves frequent steam sterilization or higher impact toughness — PPSU has significantly better hydrolysis resistance and durability under repeated autoclave cycles, though at a higher cost. We supply both, so we can help match the grade to your budget and performance needs.
Is this material certified for food or medical use?

SABIC-equivalent PSU/PPSU resin meets FDA and NSF compliance requirements for food and medical applications; specific certification documentation can be provided on request for your regulatory needs.
