When engineers and fabricators face a materials decision, two names come up more than almost any others: UHMW polyethylene and Nylon (polyamide). Both are proven thermoplastics trusted across food processing, marine, mechanical, and manufacturing applications—yet they behave very differently under load, in wet environments, and on the machine shop floor. Picking the wrong one doesn't just cost money; it costs uptime.
UHMW-PE (Ultra-High-Molecular-Weight Polyethylene) is defined by its extraordinarily long polymer chains—molecular weights of 3.5 to 7.5 million g/mol, versus standard HDPE at around 500,000. That chain length is the source of its toughness, near-zero moisture absorption, self-lubricating surface, and outstanding abrasion resistance. It's white, slightly waxy to the touch, and one of the most affordable engineering plastics available.
Nylon 6/6 is a polyamide whose molecular structure includes amide linkages that create strong hydrogen bonds between chains. Those bonds translate into rigidity, high compressive strength, and excellent machinability. Nylon is denser than UHMW, accepts reinforcing fillers like glass fiber and MoS₂ readily, and handles higher service temperatures. It's the go-to when mechanical performance and precise tolerances matter.
Property | UHMW-PE | Nylon 6/6 |
|---|---|---|
Density | 0.93–0.94 g/cm³ | 1.13–1.15 g/cm³ |
Tensile Strength | ~4,500 psi | ~12,000 psi |
Compressive Strength | ~3,800 psi | ~13,000 psi |
Coefficient of Friction | 0.10–0.20 | 0.20–0.40 |
Water Absorption (24h) | <0.01% | 1.0–1.5% |
Max. Service Temp. | ~180°F (82°C) | ~250°F (121°C) |
Impact Resistance | No break | 1.0–2.0 ft· lb /in |
Property | UHMW-PE | Nylon 6/6 |
|---|---|---|
Abrasion & wear | Exceptional — industry benchmark for sliding wear | Very good, but outperformed in high-abrasion scenarios |
Mechanical strength | Moderate; not suited to high compressive loads | 2–3× higher tensile and compressive strength |
Moisture resistance | Near zero absorption; stable in wet or immersed conditions | Absorbs 1–3%; can swell and shift tight tolerances |
Machinability | Machinable but waxy; needs sharp tooling and careful fixturing | Machines cleanly; tight tolerances and fine finishes achievable |
Temperature range | Good down to cryogenic; softens above ~180°F | Higher heat resistance; suitable up to ~250°F |
Noise & impact damping | Extremely quiet; absorbs shock without cracking | Moderate; can crack under severe repeated impact |
Chemical resistance | Resists most acids, bases, and solvents | Good general resistance; attacked by strong acids and some solvents |
Cost | Lower material cost per pound | Higher; specialty grades add further premium |
FDA food contact | Widely available compliant grades | Compliant grades exist; less universally stocked |
Choose UHMW when:
Abrasion and sliding wear are the primary failure mode
The environment is wet, immersed, or chemically aggressive
Noise reduction matters (conveyor guides, track liners)
Extreme or unpredictable impact loads are expected
FDA food-contact compliance is required at the lowest cost
Cryogenic temperatures are involved
Choose Nylon when:
The part must carry significant compressive or tensile load
Tight machined tolerances are required
Operating temperature exceeds 180°F (82°C)
The application is a gear, pulley, bushing, or structural bracket
Glass-fiber or MoS₂ reinforcement is needed
The environment is dry and not chemically aggressive
The most critical limitation of nylon in precision applications is its hygroscopic nature. Nylon 6/6 absorbs 1.0–1.5% moisture in a 24-hour immersion test and up to 8–9% at full saturation. Each percentage point of moisture absorption translates to roughly 0.25% dimensional change. For a 100mm bushing, that's a 0.25mm swing in diameter—easily enough to compromise a press fit or ruin a clearance tolerance.
Engineers working with nylon in variable-humidity environments must account for this in their tolerance stack-up, specify moisture-conditioning before final machining, or switch to UHMW where wet dimensional stability is non-negotiable.
UHMW is almost always cheaper per pound and per finished part. But material cost is not the same as service cost. In an abrasive conveyor application, a UHMW liner might outlast nylon by a factor of five or ten—making nylon's lower upfront price irrelevant. Conversely, a nylon gear that carries load reliably for years will outperform an UHMW alternative that creeps and deforms prematurely under compressive stress.
The right question is: what property does your application demand most? Wear resistance, load capacity, dimensional stability, or machinability? The answer usually makes the choice obvious.
There is no universally superior material between UHMW and Nylon—only the right material for a specific set of conditions. UHMW wins on wear, impact, moisture resistance, noise, and cost per surface area. Nylon wins on mechanical strength, machinability, temperature capability, and precision load-bearing applications. Map your application's primary demands to the comparison table above, and the right choice will almost always be clear.
